var geoCoordMap = {
'宝安区':[113.888821,22.560663],
'南山区':[113.935121,22.538606],
'福田区':[114.059878,22.527924],
'罗湖区':[114.138551,22.555724],
'龙华区':[114.04148,22.75794],
'盐田区':[114.242126,22.563172],
'坪山区':[114.35366,22.715809],
'龙岗区':[114.252474,22.72701]
};
//模拟数据
var attackedData1 = [
[{ name: '南山区' }, { name: '宝安区', value: 95 }],
[{ name: '南山区' }, { name: '福田区', value: 90 }],
[{ name: '南山区' }, { name: '罗湖区', value: 80 }],
[{ name: '南山区' }, { name: '龙华区', value: 70 }],
[{ name: '南山区' }, { name: '盐田区', value: 50 }],
[{ name: '南山区' }, { name: '坪山区', value: 40 }],
[{ name: '南山区' }, { name: '龙岗区', value: 30 }]
];
var planePath = 'path://M410.642 383.967l-119.088 42.143c-34.382 12.167-47.186-3.357-27.037-35.227l219.78-347.616c19.906-31.486 52.821-31.872 72.969 0l219.78 347.617c19.906 31.486 8.045 47.642-27.037 35.227l-119.088-42.143-89.078 559.012c-11.632 72.997-30.474 73.105-42.123 0l-89.078-559.012z';
/**
* lines的数据格式化
*
* @param {object} geoData 中心城市对应的地理坐标数据
* @param {object} data
* @param {boolean} origin false(default)-> 中心点作为终点;true -> 中心点作为起点;
* @returns {object} {origin:起点，destination:终点，coord：对应的坐标}
*
*/
function convertLinesData(geoData, data, origin) {
var tGeoDt = [];
var centerName,therName;
var i = 0,
len = data.length;
if (origin) {
for (i; i < len; i++) {
centerName = data[i][0].name;
otherName= data[i][1].name;
if (centerName != otherName) {
tGeoDt.push({
origin:centerName,
destination:otherName,
coords: [geoData[centerName], geoData[otherName]]//[起点，终点]
});
}
}
} else {
for (i; i < len; i++) {
centerName = data[i][0].name;
otherName= data[i][1].name;
if (centerName != otherName) {
tGeoDt.push({
origin:otherName,
destination:centerName,
coords: [geoData[otherName], geoData[centerName]]//[起点，终点]
});
}
}
}
return tGeoDt;
}
/**
* scatter的数据格式化
*
* @param {object} geoData 中心城市对应的地理坐标数据
* @param {object} data
* @param {string} centerName 中心点
* @returns {object}
*
*/
function convertScatterData(geoData, data, centerName) {
var tGeoDt = [];
for (var i = 0, len = data.length; i < len; i++) {
var tName = data[i][1].name
if (centerName != tName) {
tGeoDt.push({
name: tName,
value: [geoData[tName][0],geoData[tName][1],data[i][1].value]
});
}
}
tGeoDt.push({
name: centerName,
value: geoData[centerName],
symbolSize: 15,
itemStyle: {
normal: {
color: '#ff0000',
borderColor: '#000'
}
}
});
return tGeoDt;
}
//多个被攻击点颜色设置
var color = ['#ffffff', '#ffa022', '#46bee9'];
var series = [];
[['南山区', attackedData1]].forEach(function (item, i) {
series.push(
//设置尾迹效果
{
name: item[0],
type: 'lines',
coordinateSystem: 'bmap',
zlevel: 1,
//线特效的配置
effect: {
show: true,
//特效动画的时间
period: 6,
//特效尾迹的长度
trailLength: 0.7,
//特效尾迹的顔色
color: '#fff',
symbolSize: 3
},
lineStyle: {
normal: {
color: color[i],
width: 0,
//边的曲度
curveness: 0.2
}
},
data: convertLinesData(geoCoordMap, item[1])
},
//设置飞机图标
{
name: item[0],
//用于带有起点和终点信息的线数据的绘制
type: 'lines',
coordinateSystem: 'bmap',
zlevel: 2,
//线两端的标记类型
symbol: ['none', 'none'],
symbolSize: 10,
effect: {
show: true,
period: 6,
trailLength: 0,
//特效图形的标记
symbol: planePath,
symbolSize: 15
},
lineStyle: {
normal: {
color: '#00ffff',
width: 1,
opacity: 0.6,
curveness: 0.2
}
},
data: convertLinesData(geoCoordMap, item[1])
},
{
name: item[0],
//带有涟漪特效动画
type: 'effectScatter',
//该系列使用的坐标系
coordinateSystem: 'bmap',
zlevel: 2,
//涟漪特效相关配置
rippleEffect: {
//波纹的绘制方式
brushType: 'stroke'
},
//图形上的文本标签
label: {
normal: {
show: true,
position: 'right',
formatter: '{b}'
}
},
symbolSize: function (val) {
return val[2] / 5; ////比例
},
itemStyle: {
normal: {
areaColor: '#031525',
color: color[i]
}
},
data: convertScatterData(geoCoordMap, item[1], item[0])
}
);
});
console.log(series);
var option = {
title: {
text: '深圳市攻击图 - 基于百度地图',
left: 'center',
textStyle: {
color: '#fff'
}
},
bmap: {
center: [114.059781,22.65369], // 中心位置坐标
zoom: 11, // 地图缩放比例
roam: true, // 开启用户缩放
mapStyle: {
'styleJson': [{
'featureType': 'water',
'elementType': 'all',
'stylers': {
'color': '#031628'
}
}, {
'featureType': 'land',
'elementType': 'geometry',
'stylers': {
'color': '#000102'
}
}, {
'featureType': 'highway',
'elementType': 'all',
'stylers': {
'visibility': 'off'
}
}, {
'featureType': 'arterial',
'elementType': 'geometry.fill',
'stylers': {
'color': '#000000'
}
}, {
'featureType': 'arterial',
'elementType': 'geometry.stroke',
'stylers': {
'color': '#0b3d51'
}
}, {
'featureType': 'local',
'elementType': 'geometry',
'stylers': {
'color': '#000000'
}
}, {
'featureType': 'railway',
'elementType': 'geometry.fill',
'stylers': {
'color': '#000000'
}
}, {
'featureType': 'railway',
'elementType': 'geometry.stroke',
'stylers': {
'color': '#08304b'
}
}, {
'featureType': 'subway',
'elementType': 'geometry',
'stylers': {
'lightness': -70
}
}, {
'featureType': 'building',
'elementType': 'geometry.fill',
'stylers': {
'color': '#000000'
}
}, {
'featureType': 'all',
'elementType': 'labels.text.fill',
'stylers': {
'color': '#857f7f'
}
}, {
'featureType': 'all',
'elementType': 'labels.text.stroke',
'stylers': {
'color': '#000000'
}
}, {
'featureType': 'building',
'elementType': 'geometry',
'stylers': {
'color': '#022338'
}
}, {
'featureType': 'green',
'elementType': 'geometry',
'stylers': {
'color': '#062032'
}
}, {
'featureType': 'boundary',
'elementType': 'all',
'stylers': {
'color': '#465b6c'
}
}, {
'featureType': 'manmade',
'elementType': 'all',
'stylers': {
'color': '#022338'
}
}, {
'featureType': 'label',
'elementType': 'all',
'stylers': {
'visibility': 'off'
}
},{
"featureType": "district",
"elementType": "labels.text.fill",
"stylers": {
"color": "#ffffffff"
}
},
{
"featureType": "district",
"elementType": "labels.text.stroke",
"stylers": {
"color": "#ff0000ff"
}
}]
}
},
series: series
};
