// 绘制左侧面
const CubeLeft = echarts.graphic.extendShape({
shape: {
x: 0,
y: 0
},
buildPath: function(ctx, shape) {
// 该方法官方文档有详细的介绍，先看官网再看此此demo有助于理解
// 绘画路径是canves中的路径绘制方法
// shape参数是下面series里面的shap，
//外边的参数shape是默认值，即如果低下的shap中没有会采用默认值x:0，y:0
// 换算后的值跟canvas上一致，往下往右为正
const xAxisPoint = shape.xAxisPoint
ctx.moveTo(shape.x, shape.y);
ctx.lineTo(shape.x - 15, shape.y - 3);
ctx.lineTo(xAxisPoint[0] - 15, xAxisPoint[1] - 3);
ctx.lineTo(xAxisPoint[0], xAxisPoint[1]);
ctx.closePath()
}
})
// 绘制右侧面
const CubeRight = echarts.graphic.extendShape({
shape: {
x: 0,
y: 0
},
buildPath: function(ctx, shape) {
const xAxisPoint = shape.xAxisPoint
ctx.moveTo(shape.x, shape.y);
ctx.lineTo(shape.x + 15, shape.y - 3);
ctx.lineTo(xAxisPoint[0] + 15, xAxisPoint[1] - 3);
ctx.lineTo(xAxisPoint[0], xAxisPoint[1]);
ctx.closePath()
}
})
// 绘制顶面
const CubeTop = echarts.graphic.extendShape({
shape: {
x: 0,
y: 0
},
buildPath: function(ctx, shape) {
ctx.moveTo(shape.x, shape.y);
ctx.lineTo(shape.x + 15, shape.y - 3);
ctx.lineTo(shape.x, shape.y - 6);
ctx.lineTo(shape.x - 15, shape.y - 3);
ctx.closePath()
}
})
// 注册三个面图形
echarts.graphic.registerShape('CubeLeft', CubeLeft)
echarts.graphic.registerShape('CubeRight', CubeRight)
echarts.graphic.registerShape('CubeTop', CubeTop)
const MAX = [8, 8, 8, 8, 8]
const VALUE = [7, 6, 4, 2, 2]
const MAX_VALUE = 8
option = {
backgroundColor: "#334253",
title: {
text: '运输次数',
top: 32,
left: 18,
textStyle: {
color: 'white',
fontSize: 20
}
},
// tooltip: {
// trigger: 'axis',
// axisPointer: {
// type: 'shadow'
// },
// formatter: function(params) {
// const item = params[1]
// return item.name + ' : ' + item.value + '次';
// }
// },
grid: {
left: 40,
right: 40,
bottom: 100,
top: 100,
containLabel: true
},
xAxis: {
type: 'category',
data: ['沪A0731', '沪A0732', '沪A0733', '沪A0734', '沪A0735'],
axisLine: {
show: true,
lineStyle: {
color:'#586473'
}
},
offset: 10,
axisTick: {
show: false
},
axisLabel: {
color:'#F5F5F5'
}
},
yAxis: {
type: 'value',
axisLine: {
show: false,
// axisLabel未定义color时采用此color
lineStyle: {
color: 'white'
}
},
splitLine: {
lineStyle:{
color:'#586473'
}
},
axisTick: {
show: false
},
axisLabel: {
formatter: function (val) {
return parseInt(val/MAX_VALUE * 100) + '%' ;
}
},
},
series: [{
type: 'custom',
renderItem: function(params, api) {
// coord 是将数值转换成坐标系上的点
// x轴与y轴上的值转化为坐标点,也可以理解为维度0,1
// 如 data:[['沪A0731',7]]，api.value(0)为沪A0731，api.value(1)]为7
const location = api.coord([api.value(0), api.value(1)])
return {
type: 'group',
children: [{
type: 'CubeLeft',
shape: {
x: location[0],
y: location[1],
// x轴上的坐标点此时y轴value为0
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: 'rgba(86,105,126,.5)'
}
}, {
type: 'CubeRight',
shape: {
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: 'rgba(86,105,126,.5)'
}
}, {
type: 'CubeTop',
shape: {
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: 'rgba(86,105,126,.5)'
}
}]
}
},
data: MAX,
silent:true
}, {
type: 'custom',
renderItem: (params, api) => {
const location = api.coord([api.value(0), api.value(1)])
return {
type: 'group',
children: [{
type: 'CubeLeft',
shape: {
xValue: api.value(0),
yValue: api.value(1),
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [{
offset: 0,
color: '#C8753C'
},
{
offset: 0.25,
color: '#C8753C'
},
{
offset: 0.75,
color: '#70B2CA'
},
{
offset: 1,
color: '#70B2CA'
}
])
}
}, {
type: 'CubeRight',
shape: {
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [{
offset: 0,
color: '#C8753C'
},
{
offset: 0.25,
color: '#C8753C'
},
{
offset: 0.75,
color: '#70B2CA'
},
{
offset: 1,
color: '#70B2CA'
}
])
}
}, {
type: 'CubeTop',
shape: {
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill:'#C8753C'
}
}]
}
},
data: VALUE
},{
type: 'bar',
label: {
show: true,
position: 'top',
formatter: (params) => {
return params.value + '次'
},
color: '#fff',
offset: [0, -5]
},
itemStyle: {
color: 'transparent'
},
data: VALUE
}]
}
