var option = {
backgroundColor: '#000',
tooltip: {
show: true,
formatter: function(chart) {
var seriesName = chart.seriesName,
name = chart.name,
value = chart.value;
if (seriesName.indexOf("值") > -1) {
var html = '<span style="display:inline-block;margin-right:5px;border-radius:10px;width:10px;height:10px;background-color:#276EAF;"></span>' + name + '：' + value + "家";
return html;
}
}
},
grid: {
left: '-60',
top: '30',
right: '-60',
bottom: '-20',
containLabel: true
},
xAxis: {
show: false,
},
dataset: {
dimensions: [
'value', 'max', 'name'
],
source: [
{
value: '84',
max: '150',
name: '1 区域'
},
{
value: '150',
max: '150',
name: '2 区域'
},
{
value: '60',
max: '150',
name: '3 区域'
},
{
value: '80',
max: '150',
name: '4 区域'
},
{
value: '45',
max: '150',
name: '5 区域'
},
]
},
yAxis: [{
type: 'category',
axisTick: 'none',
axisLine: 'none',
axisLabel: {
verticalAlign: 'bottom',
align: 'left',
padding: [0, 8, 10, 5],
textStyle: {
color: '#80F5FF',
fontSize: '16',
}
},
interval: 1
}, {
type: 'category',
axisTick: 'none',
axisLine: 'none',
axisLabel: {
show: true,
verticalAlign: 'bottom',
align: 'right',
padding: [0, 8, 10, 0],
textStyle: {
color: '#fff',
fontSize: '16',
},
formatter: '{y|{value}} {x|m2}',
rich: {
y: {
color: '#80F5FF',
fontSize: 18
},
x: {
fontSize: 14,
color: 'rgba(128,245,255, 0.5)'
}
}
},
interval: 1
}],
series: [{
name: '值',
type: 'bar',
encode: {
x: 'value',
y: 'name'
},
label: {
normal: {
show: false,
position: 'right',
verticalAlign: 'bottom',
offset: [0, -10],
color: 'rgba(128,245,255,1)',
fontSize: 14,
fontFamily: 'NotoSansHans-Regular',
formatter: '{c}%'
}
},
barWidth: 6,
itemStyle: {
normal: {
color: 'rgba(128,245,255,1)',
barBorderRadius: 5,
}
},
z: 2
}, {
name: '外框',
type: 'bar',
barGap: '-100%',
encode: {
x: 'max',
y: 'value'
},
barWidth: 6,
yAxisIndex: 1,
label: {
normal: {
show: false,
position: 'right',
verticalAlign: 'bottom',
offset: [0, -10],
color: 'rgba(128,245,255,1)',
fontSize: 14,
fontFamily: 'NotoSansHans-Regular',
formatter: '{c}%'
}
},
itemStyle: {
normal: {
color: 'rgba(17,101,255, 1)',
opacity: .2,
barBorderRadius: 5,
}
},
z: 0
},
]
};
