Echarts在线免费图表


var data = [{
    name: '刑事',
    value: 2154
}, {
    name: '民事',
    value: 2000
}, {
    name: '行政',
    value: 2357
}];
var maxData = [];
var maxNumArray = [];
data.forEach(function(value, index) {
    maxNumArray.push(value.value);
})
data.forEach(function(value, index) {
    var num;
    maxData.push({
        name: value.name,
        value: Math.max.apply(null, maxNumArray)
    });
})
var scale = 1;
var rich = {
    white: {
        align: 'left',
        padding: [0, 0]
    },
};
option = {
    backgroundColor:'#0e2147',
    grid: {
        left: '7%',
        right: '7%',
        top:'28%',
        bottom: '8%',
        containLabel: true
    },
    xAxis: [{
        type: 'category',
        axisLabel:{
            textStyle:{
                 color: 'rgba(255,255,255,0.8)',
                 fontSize:14,
            },
          },
        data: ['刑事', '民事', '行政'],
        splitLine: {
            show: false
        },
        axisLine: {
            show: false
        },
        axisTick: {
            show: false
        },
    }],
    yAxis: [{
        type: 'value',
        name:'单位：天',
        nameGap:55,
        nameTextStyle:{
            color:'#ffffff',
            fontSize:16,
        },
        splitLine: {
            show: false
        },
        axisLine: {
            show:false
        },
        axisTick: {
            show: true,
            lineStyle:{
                color:'rgba(255,255,255,0.8)',
            }
        },
        axisLabel: {
            textStyle: {
                color: 'rgba(255,255,255,0.8)',
                fontSize: 14,
            }
        },
    }],
    series: [{
        name: '100',
        type: 'pictorialBar',
        stack: '总量',
        z: 3,
        barWidth: '45%',
        data: data,
        symbol: 'image://'+ fillImg,
        symbolClip: true,
            symbolSize: [40, '100%']
    }, {
        name: '占位',
        type: 'pictorialBar',
        barWidth: '45%',
        barGap: '-100%',
        silent: true,
        label: {
            normal: {
                show: true,
                position: "top",
                distance: 20,
                formatter: function(params) {
                    var stuNum = 0;
                    data.forEach(function(value, index, array) {
                        if (params.name == value.name) {
                            stuNum = value.value;
                        }
                    })
                    return stuNum ;
                },
                textStyle: {
                    fontSize:22,
                    color: "#15cbb0",
                },
                rich: rich
            }
        },
        symbol: 'image://'+ bgImg,
        symbolClip: true,
        symbolSize: [40, '100%'],
        data: maxData
    }]
};
