var category = ['服务器数（台）', '计算容量（核）', '内存容量（GB）', '存储容量（PB）'];
// var barData = [0, ~~(Math.random() * 100), ~~(Math.random() * 100), ~~(Math.random() * 100), ~~(Math.random() * 100)];
var barData = [60, 30, 82, 9];
var lineData = [100, 100, 100, 100]
var option = {
backgroundColor: '#0d073d',
grid: [{ //控制显示位置的属性grid
left: '20%',
bottom: '',
top: '',
right: '10%' //在此图中可用于控制柱子的长度
}],
xAxis: {
show: false
},
yAxis: {
data: category,
show: true,
axisLabel: {
verticalAlign: 'middle',
color: '#4488bc',
fontSize: '20'
},
axisLine: {
show: false
},
axisTick: {
show: false
}
},
series: [{ // 外边框
name: '',
type: 'pictorialBar',
symbol: 'reat',
barWidth: '10%',
symbolOffset: ['1%', 0], //位置
symbolSize: ["10500%", '500%'], //大小
itemStyle: {
normal: {
color: '#3f559c'
}
},
z: -180, //图层
symbolRepeat: null,
data: [1, 1, 1, 1], //数据
barGap: 50,
barCategoryGap: 0,
animationEasing: 'elasticOut',
},
{ // 内边框
name: '',
type: 'pictorialBar',
symbol: 'reat',
barWidth: '9%',
barMaxWidth: '20%',
symbolOffset: ['2.5%', 0],
symbolSize: ['10200%', '500%'],
itemStyle: {
normal: {
color: '#0d073d'
}
},
z: -20,
symbolRepeat: null,
data: [1, 1, 1, 1],
barGap: 45,
barCategoryGap: 0,
animationEasing: 'elasticOut',
},
{ // 蓝柱下面方块
name: '',
type: 'pictorialBar',
symbol: 'roundRect',
barWidth: '30%',
symbolOffset: ['200%', '-30%'],
itemStyle: {
normal: {
color: '#1F4683'
}
},
z: -11,
symbolRepeat: true,
symbolSize: ['20%', '120%'],
data: lineData,
barGap: 50,
barCategoryGap: 0,
animationEasing: 'elasticOut',
},
{ // 蓝柱
name: '', // blue bar
type: 'pictorialBar',
symbol: 'roundRect',
barWidth: '30%',
symbolOffset: ['200%', '-30%'],
itemStyle: {
normal: {
barMaxWidth: '20%',
barBorderRadius: 100,
color: '#6DE8FA',
}
},
symbolRepeat: true,
symbolSize: ['20%', '120%'],
// symbolClip: true,
data: barData,
},
],
}
