            // ！！！echarts需要是5.0.0.版本以上
// 这个示例使用的是graph的拖拽功能
// 1。data必须是draggable
// 2. series的layout必须是'force'
// 3. 在渲染完后需要把节点设置成固定

// 数据里必须设置draggable
var data = [
        { name: '1', draggable: true, value: { serviceId:'crux-gateway', type: 0,category:0,url:'/crux-appmodule/api/appmodule' },x:0,y:100, draggable: true,fixed:true,symbol: symbol2 },
        { name: '2', draggable: true, value: { serviceId:'crux-gateway1', type: 1,category:1,url:'/crux-appmodule/api/appmodule'},x:100,y:100, category: 1, draggable: true,fixed:true,symbol: symbol1 },
        { name: '3', draggable: true, value: { serviceId:'crux-gateway2', type: 1,category:1,url:'/crux-appmodule/api/appmodule/2' }, x:200,y:100,category: 1, draggable: true,fixed:true,symbol: symbol1 },
        { name: '4', draggable: true, value: { serviceId:'crux-gateway', type: 0,category:0,url:'/crux-appmodule/api/appmodule' },x:300,y:0, draggable: true,fixed:true,symbol: symbol2 },
        { name: '5', draggable: true, value: { serviceId:'crux-gateway1', type: 1,category:1,url:'/crux-appmodule/api/appmodule'},x:300,y:100, category: 1, draggable: true,fixed:true,symbol: symbol1 },
        { name: '6', draggable: true, value: { serviceId:'crux-gateway2', type: 1,category:1,url:'/crux-appmodule/api/appmodule/2' },x:300,y:200, category: 1, draggable: true,fixed:true,symbol: symbol1 },
     ]

const legend = {
    show: true,
    itemWidth: 20,
    itemHeight: 20,
    data: [
        { name: '成功', icon: symbol2 },
        { name: '失败', icon: symbol1 },
    ]
}
const series = {
    type: 'graph',
    roam:true,
    nodeScaleRatio:0,
    layout: 'force', // 如果想要使用graph的拖拽功能，layout必须是force
    autoCurveness:false,
    scaleLimit:{
      min:0.5,
      max:3
    },
    symbolSize: 40,
    categories: [ { name: "成功" }, { name: "失败" }],
    label: {
        show: true,
        position:[-20,40],
        align: 'center',
        textStyle: { fontSize: 12, color: '#fff' },
        "borderRadius": [
          0,
          0,
          5,
          5
        ],
        formatter: params => {
            return `{label${params.value.type}|serviceId：}{value|${params.value.serviceId}}\n{label${params.value.type}|url：}{value|${params.value.url}}`
        },
        rich: {
              "label0": {
                "backgroundColor": "#00cc66",
                "color": "#fff",
                "width": 60,
                "height": 30,
                "padding": [
                  0,
                  5,
                  0,
                  10
                ],
                "align":'left'
              },
              "label1": {
                "backgroundColor": "#ff0000",
                "color": "#fff",
                "width": 60,
                "height": 30,
                "padding": [
                  0,
                  5,
                  0,
                  10
                ],
                "align":'left'
              },
              "value": {
                "color": "#888",
                "align": "center",
                "lineHeight": 17,
                "height": 30,
                "borderColor": "#eee",
                "borderWidth": 1,
                "padding": [
                  0,
                  5,
                  0,
                  5
                ]
              }
        }
    },
    labelLayout: function(param){
        return {
            moveOverlap:true,
            hideOverlap:true
        }
    },
    edgeSymbol: ['none', 'arrow'],
    edgeSymbolSize: [4, 8],
    data: data,
    links: [
        { source: 0, target: 1, value: '',},
        { source: 1, target: 2, value: '', },
        { source: 2, target: 3, value: '', },
        { source: 2, target: 4, value: '', },
        { source: 2, target: 5, value: '', },
    ],
    lineStyle: {
        opacity: 0.9,
        width: 2,
        color: '#333'
    }
}

option = { series, legend }
setTimeout(function() {
  // 源码中在dragend里将node设为了unfixed，变成了浮动
  // 因此需要增加一下dragend监听，将node设置成固定
  var seriesModel = myChart.getModel().getSeriesByIndex(0)
  seriesModel.getData().graph.eachNode(node=>{
    var el = node.getGraphicEl();
    var idx = node.dataIndex;
    var itemModel = node.getModel();
    var draggable = itemModel.get('draggable');
    if(draggable){
      el.on('dragend', function () {
      var forceLayout = seriesModel.forceLayout;
        if (forceLayout) {
          forceLayout.setFixed(idx);
        }
      });
    }
  })
}, 10);
