// 借鉴修改得 https://www.isqqw.com/viewer?id=15110 https://www.isqqw.com/viewer?id=38641
const offsetX = 12;
const offsetY = 6;
const barWidth = 30
// 绘制左侧面
const CubeLeft = echarts.graphic.extendShape({
shape: {
x: 0,
y: 0,
},
buildPath: function (ctx, shape) {
// 会canvas的应该都能看得懂，shape是从custom传入的
const xAxisPoint = shape.xAxisPoint;
// console.log(shape);
const c0 = [shape.x, shape.y];
const c1 = [shape.x - offsetX, shape.y - offsetY];
const c2 = [xAxisPoint[0] - offsetX, xAxisPoint[1] - offsetY];
const c3 = [xAxisPoint[0], xAxisPoint[1]];
ctx.moveTo(c0[0], c0[1]).lineTo(c1[0], c1[1]).lineTo(c2[0], c2[1]).lineTo(c3[0], c3[1]).closePath();
},
});
// 绘制右侧面
const CubeRight = echarts.graphic.extendShape({
shape: {
x: 0,
y: 0,
},
buildPath: function (ctx, shape) {
const xAxisPoint = shape.xAxisPoint;
const c1 = [shape.x, shape.y];
const c2 = [xAxisPoint[0], xAxisPoint[1]];
const c3 = [xAxisPoint[0] + offsetX, xAxisPoint[1] - offsetY];
const c4 = [shape.x + offsetX, shape.y - offsetY];
ctx.moveTo(c1[0], c1[1]).lineTo(c2[0], c2[1]).lineTo(c3[0], c3[1]).lineTo(c4[0], c4[1]).closePath();
},
});
// 绘制顶面
const CubeTop = echarts.graphic.extendShape({
shape: {
x: 0,
y: 0,
},
buildPath: function (ctx, shape) {
const c1 = [shape.x, shape.y];
const c2 = [shape.x + offsetX, shape.y - offsetY]; //右点
const c3 = [shape.x, shape.y - offsetX];
const c4 = [shape.x - offsetX, shape.y - offsetY];
ctx.moveTo(c1[0], c1[1]).lineTo(c2[0], c2[1]).lineTo(c3[0], c3[1]).lineTo(c4[0], c4[1]).closePath();
},
});
// 注册三个面图形
echarts.graphic.registerShape('CubeLeft', CubeLeft);
echarts.graphic.registerShape('CubeRight', CubeRight);
echarts.graphic.registerShape('CubeTop', CubeTop);
const colorArr = [
['#0099FF', '#0266ab', '#B6E9FF'],
['#00fbf7', '#02a3a9', '#A7FFDF'],
['#4A9880', '#70D6B5', '#A7FFDF']
]
let series = []
let xData = ['上行PRB利用率(%)', '下行PRB利用率(%)', '上行吞吐率(%)', '下行吞吐率(%)', '上行DB引用率', '下行DB引用率']
let legendArr = ['扩容前', '扩容后', '更新前']
let datas = [
['20', '30', '40', '50', '30', '40',],
['70', '80', '80', '70', '80', '70'],
['50', '40', '30', '20', '30', '20'],
]
datas.forEach((item, index) => {
series.push({
type: 'custom',
name: legendArr[index],
renderItem: (params, api) => {
const location = api.coord([api.value(0), api.value(1)]);
return {
type: 'group',
x: (index - datas.length / 2) * barWidth + 15,
children: [
{
type: 'CubeLeft',
shape: {
api,
xValue: api.value(0),
yValue: api.value(1),
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0]),
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [
{
offset: 0,
color: colorArr[index % colorArr.length][1],
},
{
offset: 1,
color: colorArr[index % colorArr.length][0],
},
]),
},
},
{
type: 'CubeRight',
shape: {
api,
xValue: api.value(0),
yValue: api.value(1),
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0]),
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [
{
offset: 0,
color: colorArr[index % colorArr.length][1],
},
{
offset: 1,
color: colorArr[index % colorArr.length][0],
},
]),
},
},
{
type: 'CubeTop',
shape: {
api,
xValue: api.value(0),
yValue: api.value(1),
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0]),
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [
{
offset: 0,
color: colorArr[index % colorArr.length][0],
},
{
offset: 1,
color: colorArr[index % colorArr.length][0],
},
]),
},
},
],
};
},
data: item
}, {
type: 'bar',
name: legendArr[index],
barWidth: 25,//当前适配，更改需要同时更改 offsetX,offsetY,barWidth
label: {
normal: {
show: true,
position: 'top',
// formatter: (e) => {
// return e.value + '次';
// },
fontSize: 16,
color: '#43C4F1',
offset: [0, -10],
},
},
itemStyle: {
color: 'transparent',
},
tooltip: {},
data: item,
})
})
option = {
backgroundColor: '#012366',
tooltip: {
trigger: 'axis',
borderWidth: 0,
backgroundColor: 'rgba(8,36,68,.7)',
color: '#fff',
textStyle: {
color: '#fff'
},
formatter: function (params, ticket, callback) {
console.log(params)
let str = params[0].name + '</br>';
params.forEach((item, index) => {
if (item.seriesType == 'custom') //避免上方数字的bar也展示tooltip数据
str += `
<div style='display:flex;justify-content:space-between;align-items:center'>
<div style='margin-right:20px;'>
<span style="display:inline-block;width:10px;height:10px;border-radius:5px;background-color:${colorArr[index % colorArr.length][0]}"></span>
${item.seriesName}
</div>
<span> ${item.value ? item.value : '-'}</span>
</div>`
})
return str;
},
},
grid: {
left: 40,
right: 40,
top: 200,
bottom: 35,
containLabel: true
},
legend: {
right: '20',
top: '40',
show: true,
selectedMode: false, // 取消图例点击事件 目前图例显示隐藏指标值位置会错误
textStyle: {
color: 'white',
fontSize: 16
},
data: legendArr.map((item, index) => {
return {
name: item,
textStyle: {
color: 'white',
fontSize: 16
},
itemStyle: {
color: colorArr[index % colorArr.length][0],
}
};
}),
},
xAxis: {
type: 'category',
data: xData,
axisLine: {
show: true,
lineStyle: {
color: '#045d79'
// width: 2
}
},
axisTick: {
show: false
},
axisLabel: {
color: 'white',
fontSize: 14
}
},
yAxis: {
type: 'value',
axisLabel: {
color: 'white',
fontSize: 14
},
splitLine: {
show: false
},
show: false
},
series: series,
//数据过多避免重叠
dataZoom: [
{
show: true,
height: 10,
xAxisIndex: [0],
bottom: 20,
showDetail: false,
borderColor: 'transparent',
textStyle: {
fontSize: 0,
},
endValue: 12 / datas.length, //从0开始的相当于5个x轴的数据
backgroundColor: 'rgba(0,0,0,0)',
borderWidth: 0,
handleSize: '0%',
handleStyle: {
color: '#d3dee5',
},
},
]
}
