let arr = [];
let list = [];
let series = [];
let legend = [];
let fontSize = 16;
let barWidth = 26;
let barGap = 0;
let maxList = [];
let max = 460; //背景最大值取y轴刻度线（最后注释部分）
let colorStartList = ['transparent', 'transparent', 'transparent', 'transparent'];
let colorLeftList = ['#000', '#000', '#000', '#000'];
let colorTopList = ['#1E7EFF', '#FFA75A', '#6ACC29', '#9833FF'];
let colorEndList = ['#4084EE', '#FF8D28', '#6ACC29', '#9833FF'];
chartObj = {
series: [
{ name: '当前资源', data: [269, 460, 400, 170] },
{ name: '其他资源', data: [39, 50, 40, 100] },
{ name: '资源', data: [15, 200, 80, 60] },
{ name: '资源2', data: [15, 200, 80, 60] },
],
chartList: ['通信', '网络', '能源', '建筑'],
};
function colorRgba(str, alpha) {
let reg = /^#([0-9a-fA-f]{3}|[0-9a-fA-f]{6})$/;
var sColor = str.toLowerCase();
if (sColor == 'transparent') {
return 'transparent';
}
if (sColor && reg.test(sColor)) {
if (sColor.length === 4) {
var sColorNew = '#';
for (let i = 1; i < 4; i += 1) {
sColorNew += sColor.slice(i, i + 1).concat(sColor.slice(i, i + 1));
}
sColor = sColorNew;
}
//处理六位的颜色值
var sColorChange = [];
for (let i = 1; i < 7; i += 2) {
sColorChange.push(parseInt('0x' + sColor.slice(i, i + 2)));
}
return 'rgba(' + sColorChange.join(',') + ',' + alpha + ')';
} else {
return sColor;
}
}
if (chartObj.series && chartObj.series.length) {
chartObj.series.forEach((ele, i) => {
arr = arr.concat(ele.data);
});
maxList = chartObj.series[0].data.map(() => {
return max;
});
list = chartObj.series[0].data.map((item, index) => {
return 1;
});
chartObj.series.forEach((item, index) => {
legend.push({
name: item.name,
itemStyle: {
color: colorEndList[index % colorEndList.length],
},
});
//背景顶部切片
series.push({
data: maxList,
type: 'pictorialBar',
barMaxWidth: fontSize * 3,
itemStyle: {
color: colorEndList[index],
opacity: 0.1,
},
tooltip: {
show: false,
},
symbolPosition: 'end',
symbol: 'diamond',
symbolOffset: [
(-0.5 * (chartObj.series.length - 1) +
index +
-0.5 * barGap * 0.01 * (chartObj.series.length - 1) +
barGap * 0.01 * index) *
barWidth,
'-50%',
],
symbolSize: [barWidth, barWidth * 0.4],
zlevel: -1,
});
//底部切片
series.push({
data: list,
color: colorStartList[index % colorStartList.length],
type: 'pictorialBar',
tooltip: {
show: false,
},
barMaxWidth: fontSize * 3,
symbol: 'diamond',
symbolOffset: [
(-0.5 * (chartObj.series.length - 1) +
index +
-0.5 * barGap * 0.01 * (chartObj.series.length - 1) +
barGap * 0.01 * index) *
barWidth,
'50%',
],
symbolSize: [barWidth, barWidth * 0.5],
});
//实际数据顶部切片
series.push({
data: item.data,
type: 'pictorialBar',
tooltip: {
show: false,
},
barMaxWidth: fontSize * 3,
color: colorTopList[index],
symbolPosition: 'end',
symbol: 'diamond',
symbolOffset: [
(-0.5 * (chartObj.series.length - 1) +
index +
-0.5 * barGap * 0.01 * (chartObj.series.length - 1) +
barGap * 0.01 * index) *
barWidth,
'-50%',
],
symbolSize: [barWidth, barWidth * 0.4],
zlevel: 2,
});
//实际数据侧边切片
series.push({
data: item.data,
type: 'pictorialBar',
tooltip: {
show: false,
},
barMaxWidth: fontSize * 3,
color: {
x: 0,
y: 1,
x2: 0,
y2: 0,
type: 'linear',
global: false,
colorStops: [
{
offset: 0,
color: 'transparent',
},
{
offset: 0.2,
color: colorRgba(colorLeftList[index % colorLeftList.length], 0.2),
},
{
offset: 1,
color: colorRgba(colorLeftList[index % colorLeftList.length], 0.3),
},
],
},
symbolPosition: 'end',
symbol: 'rect',
symbolSize: [barWidth / 2, '100%'],
symbolOffset: [
(-0.5 * (chartObj.series.length - 1) +
index +
-0.5 * barGap * 0.01 * (chartObj.series.length - 1) +
barGap * 0.01 * index -
0.25) *
barWidth,
0,
],
zlevel: 1,
});
//柱子
series.push({
data: item.data,
type: 'bar',
name: item.name,
barGap: barGap + '%',
barWidth: barWidth,
barMaxWidth: fontSize * 3,
label: {
show: false,
position: 'top',
distance: fontSize * 0.3,
textStyle: {
color: colorEndList[index % colorEndList.length],
fontSize: fontSize,
},
// formatter: function (a, b) {
// return a.value==0?'':a.value;
// },
},
showBackground: true,
backgroundStyle: {
color: {
x: 0,
y: 1,
x2: 0,
y2: 0,
type: 'linear',
global: false,
colorStops: [
{
offset: 0,
color: colorStartList[index % colorStartList.length],
},
{
offset: 0.2,
color: colorRgba(colorEndList[index % colorEndList.length], 0.2),
},
{
offset: 1,
color: colorRgba(colorEndList[index % colorEndList.length], 1),
},
],
},
opacity: 0.1,
},
itemStyle: {
color: {
x: 0,
y: 1,
x2: 0,
y2: 0,
type: 'linear',
global: false,
colorStops: [
{
offset: 0,
color: colorStartList[index % colorStartList.length],
},
{
offset: 0.2,
color: colorRgba(colorEndList[index % colorEndList.length], 0.2),
},
{
offset: 1,
color: colorRgba(colorEndList[index % colorEndList.length], 1),
},
],
},
},
});
});
}
option = {
// backgroundColor: "#061326",
title: {
text: '',
top: 20,
left: 'center',
textStyle: {
color: '#fff',
fontSize: 20,
},
},
tooltip: {
show: true,
trigger: 'axis',
backgroundColor: 'rgba(116,176,222,0.3)',
extraCssText: 'box-shadow: 0 0 8px rgba(0, 128, 255, 0.27) inset;',
borderWidth: 0,
confine: false,
appendToBody: true,
formatter: (params) => {
////console.log(params,'---paramsshopping')
let result = "<div style='margin-bottom:5px;'>" + params[0].name + '</div>';
params.forEach((item, index) => {
var dotHtml = `<span style="display:inline-block;margin-right:5px;border-radius:50%;width:${fontSize}px;height:${fontSize}px;background:${colorEndList[index]}"></span>`;
result +=
"<div style='display:flex;align-items:center;margin-bottom:5px'>" +
dotHtml +
item.seriesName +
(item.seriesName ? "<span style='display:inline-block;margin-right:6px;'></span>" : '') +
item.data +
'</div>';
});
return result;
},
//轴触发提示才有效
axisPointer: {
type: 'shadow',
shadowStyle: {
color: 'rgba(35,49,77,0.01)',
},
},
textStyle: {
color: '#fff',
fontSize: fontSize,
},
},
grid: {
top: fontSize * 3.5,
left: 5,
right: 5,
bottom: fontSize,
containLabel: true, //包括文本，居中
},
legend: {
show: true,
data: legend,
selectedMode: false, //图例是否可以点击
type: 'scroll',
icon: 'circle',
itemWidth: fontSize,
itemHeight: fontSize,
textStyle: {
color: '#C3E3F9',
fontSize: fontSize,
},
},
xAxis: {
data: chartObj.chartList,
type: 'category',
axisLine: {
show: true,
lineStyle: {
color: '#2B72A1',
},
},
axisLabel: {
fontSize: fontSize,
color: '#87CCFF',
},
splitLine: {
show: false,
},
axisTick: {
show: false,
},
interval: 0,
},
yAxis: [
{
type: 'value',
name: '单位',
nameGap: fontSize * 1.5,
nameTextStyle: {
align: 'center',
fontSize: fontSize,
color: '#2869A9',
},
splitNumber: 4,
splitLine: {
show: true,
lineStyle: {
color: 'rgba(255,255,255,0.1)',
},
},
axisLine: {
show: false,
},
axisLabel: {
margin: 10,
fontSize: fontSize,
color: '#2869A9',
},
axisTick: {
show: true,
lineStyle: {
color: '#2869A9',
},
},
},
],
series: series,
};
