option = { title: { // 标题居中显示 left: 'center', // 标题名称 text: 'Awesome Chart' }, tooltip: { trigger: 'axis', axisPointer: { type: 'cross' }, formatter: function(params) { var htmlHeader = '

时间：2020-12-12 01:00:00

' + '

单位：(MW)

'; var htmlList = '' for (var i = 0; i < params.length; i++) { const item = params[i] htmlList = ( htmlList + '

' + item.marker + ''+ item.name +':'+item.value[1] +'（'+ item.value[2] +'MW）' +'

' ) } return (htmlHeader + htmlList) } }, grid: { bottom: 80 }, legend: { data: [], left: 70, bottom: 0 }, xAxis: { type: 'time', // x 轴单位标注 name: '时间', axisTick: { // x 轴线上的刻度点在轴线内显示 inside: true }, axisLine: { // x 轴线两端的形状 symbol: ['none', 'arrow'] } }, yAxis: { type: 'value', name: '单位: 元', axisTick: { // y 轴线上的刻度点在轴线内显示 inside: true }, // max: 120, max: 2000, axisLine: { // y 轴线两端的形状 symbol: ['none', 'arrow'] } }, series: [{ type: 'line', name: '江苏', // 标准线 markLine: { show: true, // 标准线两端的形状 symbol: ['none', 'none'], label: { // 标准线上数字显示的位置 position: 'middle', }, data: [ // 标准线大小位置 { name: '额定', yAxis: 30 } ] }, data:[] }] }; const city = [ { name: '江苏' }, { name: '南京' }, { name: '无锡' }, // { name: '泰州' }, // { name: '扬州' }, // { name: '苏州' }, // { name: '徐州' }, // { name: '连云港' }, // { name: '盐城' }, // { name: '淮安' }, // { name: '宿迁' }, // { name: '镇江' }, // { name: '南通' }, // { name: '常州' }, ] function setSeriesItemData (name) { const data = [] const legend = [] for (let i = 0; i < city.length; i++) { const name = city[i].name legend.push(name) data.push({ type: 'line', name, // 折线每个点上的形状 symbol: 'none', smooth: true, markLine: { show: true, data: [ { name: '标准线', yAxis: 1300 } ] }, data: getLineData(name) }) } option.legend.data = legend option.series = data } function getLineData (name) { const data = [] const date = '2020/01/01 00:00:00' let datetime = 1577808000000 - 86400000 for (let i =0; i < 120; i++) { datetime = datetime + 86400000 data.push({ name, value: [ moment(new Date(datetime)).format('YYYY-MM-DD hh:mm:ss'), (Math.random() * 1000).toFixed(2), (Math.random() * 1000).toFixed(2) ] }) } return data } setSeriesItemData() myChart.setOption(option);
