// 绘制左侧面
const CubeLeft = echarts.graphic.extendShape({
shape: {
x: 0,
y: 0,
},
buildPath: function (ctx, shape) {
// console.log('shape',shape.xAxisPoint)
const xAxisPoint = shape.xAxisPoint;
const c0 = [shape.x - 30, shape.y];
const c1 = [shape.x + 1, shape.y + 20];
const c2 = [xAxisPoint[0] + 1, xAxisPoint[1] + 20];
const c3 = [xAxisPoint[0] - 30, xAxisPoint[1]];
ctx
.moveTo(c0[0], c0[1])
.lineTo(c1[0], c1[1])
.lineTo(c2[0], c2[1])
.lineTo(c3[0], c3[1])
.closePath();
},
});
const CubeRight = echarts.graphic.extendShape({
shape: {
x: 0,
y: 0,
},
buildPath: function (ctx, shape) {
const xAxisPoint = shape.xAxisPoint;
const c1 = [shape.x + 30, shape.y];
const c2 = [xAxisPoint[0] + 31, xAxisPoint[1] + 5];
const c3 = [xAxisPoint[0], xAxisPoint[1] + 20];
const c4 = [shape.x, shape.y];
ctx
.moveTo(c1[0], c1[1])
.lineTo(c2[0], c2[1])
.lineTo(c3[0], c3[1])
.lineTo(c4[0], c4[1])
.closePath();
},
});
const CubeTop = echarts.graphic.extendShape({
shape: {
x: 0,
y: 0,
},
buildPath: function (ctx, shape) {
const c1 = [shape.x - 30, shape.y];
const c2 = [shape.x, shape.y - 15]; //右点
const c3 = [shape.x + 30, shape.y];
const c4 = [shape.x, shape.y + 20];
ctx
.moveTo(c1[0], c1[1])
.lineTo(c2[0], c2[1])
.lineTo(c3[0], c3[1])
.lineTo(c4[0], c4[1])
.closePath();
},
});
// 注册三个面图形
echarts.graphic.registerShape('CubeLeft', CubeLeft)
echarts.graphic.registerShape('CubeRight', CubeRight)
echarts.graphic.registerShape('CubeTop', CubeTop)
const VALUE = [2016, 1230, 3790]
option = {
backgroundColor: "rgb(1, 12, 36)",
tooltip: {
trigger: 'axis',
axisPointer: {
type: 'shadow'
},
formatter: function(params, ticket, callback) {
const item = params[1]
return item.name + ' : ' + item.value;
}
},
grid: {
left: '10%',
right: '10%',
top: '15%',
bottom: '10%',
containLabel: true
},
xAxis: {
type: 'category',
data: ['雄县', '安新', '容城'],
axisLine: {
show: true,
lineStyle: {
color: 'white'
}
},
axisTick: {
show: false,
length: 9,
alignWithLabel: true,
lineStyle: {
color: '#7DFFFD'
}
},
axisLabel: {
fontSize: 20
}
},
yAxis: {
type: 'value',
axisLine: {
show: true,
lineStyle: {
color: 'white'
}
},
splitLine: {
show: false
},
axisTick: {
show: false
},
axisLabel: {
fontSize: 16
},
boundaryGap: ['20%', '20%']
},
series: [{
type: 'custom',
renderItem: (params, api) => {
const location = api.coord([api.value(0), api.value(1)])
return {
type: 'group',
children: [{
type: 'CubeLeft',
shape: {
api,
xValue: api.value(0),
yValue: api.value(1),
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [{
offset: 0,
color: 'rgba(55, 64, 110,0.2)'
},
{
offset: 1,
color: 'rgba(55, 64, 110,0.2)'
}
])
}
}, {
type: 'CubeRight',
shape: {
api,
xValue: api.value(0),
yValue: api.value(1),
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [{
offset: 0,
color: '#f40'
},
{
offset: 1,
color: '#f40'
}
])
}
}, {
type: 'CubeTop',
shape: {
api,
xValue: api.value(0),
yValue: api.value(1),
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [{
offset: 0,
color: '#f40'
},
{
offset: 1,
color: '#f40'
}
])
}
}]
}
},
data: VALUE
}, {
type: 'bar',
stack: "统筹区域",
itemStyle: {
color: 'transparent'
},
tooltip: {
},
data: VALUE
},{
type: 'custom',
renderItem: (params, api) => {
const location = api.coord([api.value(0), api.value(1)])
return {
type: 'group',
children: [{
type: 'CubeLeft',
shape: {
api,
xValue: api.value(0),
yValue: api.value(1),
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [{
offset: 0,
color: 'rgba(0, 64, 110,1)'
},
{
offset: 1,
color: 'rgba(0, 64, 110,1)'
}
]),
borderColor: '#fff',
borderWidth:1,
stroke:'#fff',
// lineWidth:10
},
}, {
type: 'CubeRight',
shape: {
api,
xValue: api.value(0),
yValue: api.value(1),
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [{
offset: 0,
color: '#f40'
},
{
offset: 1,
color: '#f40'
}
]),
},
// itemStyle:{
// borderColor: '#fff',
// borderWidth:1,
// borderType : 'solid'
// },
}, {
type: 'CubeTop',
shape: {
api,
xValue: api.value(0),
yValue: api.value(1),
x: location[0],
y: location[1],
xAxisPoint: api.coord([api.value(0), 0])
},
style: {
fill: new echarts.graphic.LinearGradient(0, 0, 0, 1, [{
offset: 0,
color: '#f40'
},
{
offset: 1,
color: '#f40'
}
])
}
}]
}
},
data: VALUE
}, {
type: 'bar',
stack: "统筹区域",
itemStyle: {
color: 'transparent'
},
tooltip: {
},
data: VALUE
}]
}
